Rear Wheel Toe-In: Adjustment

Loosen self-locking nut on inner side of link rear.
CAUTION:
- When loosening or tightening adjusting bolt, hold bolt head and turn self-locking nut.
- Discard loosened self-locking nut and replace with a new one.

  Fig 1: Identifying Adjusting Bolt & Rear Link
  Courtesy of SUBARU OF AMERICA, INC.
Turn adjusting bolt head until toe-in is at the specification.
NOTE: When left and right wheels are adjusted for toe-in at the same time, the movement of one scale graduation changes toe-in by approximately 3 mm (0.12 in).

Fig 2: Identifying Scale Graduations On Adjustment Bolts
Courtesy of SUBARU OF AMERICA, INC.
Tighten self-locking nut.
1. Tightening torque: 12 N.m (12.2 kgf-m, 88 ft-lb)
