Cigarette Lighter: Removal

  1. Disconnect ground cable from battery.
  2. Remove center panel. Refer to REMOVAL  , Radio Body.
  3. Disconnect harness connectors and remove cigarette lighter.
    Fig 1: Disconnecting Harness Connectors & Removing Cigarette Lighter
    G02961700Courtesy of SUBARU OF AMERICA, INC.
