Back Panel Tray: Installation
WARNING: This page is about a different car, the 2004 Subaru Outback, 2004 Subaru Legacy, and 2004 Subaru Baja. However, it is still accessible from the selected car via links, so may be relevant.
- Replace all clips on the reverse of back panel tray with new ones.
Courtesy of SUBARU OF AMERICA, INC.
- Install in the reverse order of removal.
Tightening torque:
Cargo bed side molding;
7.5 N.m (0.76 kgf-m, 5.53 ft-lb)
Cargo bed side tray;
7.5 N.m (0.76 kgf-m, 5.53 ft-lb)
