Back-up Light Bulb: Removal: Wagon

WARNING: This page is about a different car, the 2002 Subaru Outback and 2002 Subaru Legacy. However, it is still accessible from the selected car via links, so may be relevant.
  1. Open rear gate lower trim cover.
    Fig 1: Opening Rear Gate Lower Trim Cover
    G02961966Courtesy of SUBARU OF AMERICA, INC.
  2. Turn the socket and remove the bulb.
