Master Cylinder Assembly: Notes

WARNING: This page is about a different car, the 2002 Subaru Forester and 2001 Subaru Forester. However, it is still accessible from the selected car via links, so may be relevant.

NOTE: Before disassembling and reassembling master cylinder assembly, identify the master cylinder components. See Fig 1 .

Fig 1: Identifying Master Cylinder Components (Without ABS)

Courtesy of SUBARU OF AMERICA, INC.
