Front Washer Switch Continuity Test
- Check continuity between terminals d-2 (White wire) and d-5 (Black wire) of combination switch connector. SeeFig 1 .
- Continuity should be present with washer switch turned on. Continuity should not be present when washer switch is turned off. Repair or replace as necessary.
