Steering System - Power: Description

The system consists of a fluid reservoir, power steering pump, pressure and return fluid lines, control valve and rack and pinion assembly. The power steering pump applies fluid pressure to the control valve which assists in the turning of the wheels.

Fig 1: Exploded View of Subaru XT Steering System
G52899Courtesy of SUBARU OF AMERICA, INC.
