Centrifugal Advance

Check distributor in a test stand according to test equipment manufacturer's instructions. Operate distributor up and down the RPM range and check advance at all RPM settings specified.

Fig 1: Typical Centrifugal Advance
G09350968Courtesy of NOT AVAILABLE
