Inner Rear View Mirror: Installation

  1. INSTALL INNER REAR VIEW MIRROR ASSEMBLY
    1. Install the mirror in the direction of the white arrow.
    2. Install the cover as shown in the illustration.
      Fig 1: Installing Inner Rear View Mirror Assembly
      G04159053Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
