Installation Procedure

WARNING: This page is about a different car, the 2005 Saturn L300. However, it is still accessible from the selected car via links, so may be relevant.
    Fig 1: Removing & Installing Rear Load Floor
    GM896668Courtesy of GENERAL MOTORS CORP.
  1. Position the load floor into the vehicle.
  2. Slide the load floor tabs into the front load floor assembly.
  3. Lower the load floor.
  4. Reposition the load floor side wings.
