Installation Procedure

WARNING: This page is about a different car, the 2007 Pontiac Montana SV6, 2007 Chevrolet Uplander, and 2007 Buick Terraza. However, it is still accessible from the selected car via links, so may be relevant.
    Fig 1: View Of Speaker Assembly
    GM319781Courtesy of GENERAL MOTORS CORP.
  1. Snap the speaker into the lock module.
  2. Connect the electrical connector.
  3. Install the front door trim panel. Refer to Front Side Door Trim Panel Replacement .
