Installation Procedure

WARNING: This page is about a different car, the 2005 Chevrolet Malibu. However, it is still accessible from the selected car via links, so may be relevant.
    Fig 1: View Of Bulb From Rear Compartment Lamp
    GM1215808Courtesy of GENERAL MOTORS CORP.
  1. Install the bulb to the rear compartment lamp.
  2. Connect the electrical connector to the rear compartment lamp.
  3. Install the rear compartment lamp to the rear shelf pressing into place until fully seated.
  4. Close the rear compartment.
