Removal Procedure

    IMPORTANT: Record all pre-set radio stations.
  1. Turn the ignition OFF.
  2. Disconnect the negative battery cable. Refer to Battery Negative Cable Disconnect/Connect Procedure .
    3. Fig 1: View Of Generator (L66)
    GM1226453Courtesy of GENERAL MOTORS CORP.
  3. Remove the air cleaner assembly. Refer to Air Cleaner Assembly Replacement in Engine Controls - 3.5L (L66).
  4. Remove the accessory drive belt tensioner. Refer to Drive Belt Tensioner Replacement in Engine Mechanical - 3.5L (L66).
  5. Install the engine support fixture. Refer to Engine Support Fixture in Engine Mechanical - 3.5L (L66).
  6. Remove the front of the engine mount through bolt and raise the engine for proper clearance.
    7. Fig 2: View Of Generator Electrical Connectors
    GM1228610Courtesy of GENERAL MOTORS CORP.
  7. Disconnect the generator electrical connections.
    8. Fig 3: View Of Generator & Install The Top Bolts
    GM1237805Courtesy of GENERAL MOTORS CORP.
  8. Remove the generator to engine block bolts and the generator.
