Cooling Fan Control Module: Removal

  1. Disconnect negative battery cable.
  2. Use screwdriver to release retaining tab on cooling fan control module and remove module by sliding up and off bracket.
    Fig 1: Locating Cooling Fan Control Module
    G01036555Courtesy of GENERAL MOTORS CORP.
  3. Disconnect cooling fan control module electrical connectors.
