Home >> Saturn >> 2002 >> L100 >> Repair and Diagnosis >> Engine Mechanical >> Mechanical >> General Information >> Specifications >> Cylinder Head (Front View)

Cylinder Head (Front View)

Fig 1: Cylinder Head (Front View)

G01020870

Courtesy of GENERAL MOTORS CORP.

Fig 2: Cylinder Head (Front View) Specifications

G01020871

Courtesy of GENERAL MOTORS CORP.
