B2482: Cellular Phone Select Service Switch Performance: Notes

Fig 1: B2482 - Cellular Phone Select Service Switch Performance Schematic

Courtesy of GENERAL MOTORS CORP.

The OnStar Communication Interface Module (CIM) monitors the Remote Control 3- Button Mirror Assembly for stuck buttons.
