Engine Support Fixture (Front Side)

WARNING: This page is about a different variant/trim than selected.
Fig 1: Identifying Engine Support Fixture And Fastener (Front Side)
G09438359Courtesy of SAAB-SCANIA OF AMERICA, INC.
Callout Component Name
Preliminary Procedure
Remove the air cleaner outlet duct. Refer to AIR CLEANER OUTLET DUCT REPLACEMENT .
1 Engine Support Fixture (Front) Fastener (Qty: 2)
Refer to FASTENER CAUTION .
Tighten
65 Nm (48 lb ft)
2 Engine Support Fixture (Front Side)
