Bulb, Replacement 4D

Fig 1: Identifying Tail Lamp Bulb And Harness Socket Fasteners

Courtesy of SAAB-SCANIA OF AMERICA, INC.

Callout	Component Name
Preliminary Procedure Remove the tail lamp. Refer to TAIL LAMP REPLACEMENT .
1	Tail Lamp Harness Socket Fastener (Qty: 6) Refer to FASTENER CAUTION .
2	Tail Lamp Bulb See AVOID TOUCHING THE BULB CAUTION . Procedure Service the bulb, as needed. Loosen the lamp by turning the bulb socket anticlockwise in relation to the tail lamp. Turn it clockwise when installing. Turn the bulb anticlockwise from the bulb socket and clockwise for refitting.
