Grounding point G30A: Notes

Fig 1: Identifying Grounding Point G30A Location
G05547359Courtesy of SAAB-SCANIA OF AMERICA, INC.

Location:  Front grounding point on the side plate above the LH front wheel housing

The grounding point is connected to grounding point G31 via crimp J1, the underhood electrical centre 342 and crimp J9/J12.
