Grounding point G43: Notes

Fig 1: Identifying Grounding Point G43
G05571004Courtesy of SAAB-SCANIA OF AMERICA, INC.

Location:  On right-hand side of knee member

The grounding point is connected with grounding point G34S via crimps J80  and J108 .
