LED (Light Emitting Diode)

Fig 1: Identifying LED (Light Emitting Diode)
G05039308Courtesy of SAAB-SCANIA OF AMERICA, INC.
LED REFERENCE

Location In the center of the dashboard
Color Red
Power supply Pin No. 2
Ground Pin No. 1
Current limit from electronic control module 20 mA
