Home >> Saab >> 2007 >> 9-3 2.0T, 2D Convertible, Standard >> Repair and Diagnosis >> Electrical >> Horns >> Lighting And Signaling Systems >> Interior Lighting >> Component Locator >> Grounding point G40 >> Notes

Grounding point G40: Notes

Fig 1: Identifying Grounding Point G40

G05171712

Courtesy of SAAB-SCANIA OF AMERICA, INC.

Location: In the instrument space to the left of the knee member
