Installation Procedure

    Fig 1: Removing/Installing Console Shift Lever Bezel
    GM1554777Courtesy of GENERAL MOTORS CORP.
  1. Position the trim plate to the console.
  2. Connect the harness connector to the accessory power outlet.
  3. Install the bezel to the console ensuring the retaining clips are fully seated.
  4. Install the ignition switch key bezel.
  5. Install the floor shift control boot to the floor console. Refer to Floor Shift Control Knob Replacement in Automatic Transmission.
  6. Install the console storage bin. Refer to Console Storage Bin Replacement .
