Freewheel rotating freely

Fig 1: Cross Section View Of Freely Rotating Freewheel
G03869331Courtesy of SAAB-SCANIA OF AMERICA, INC.
  1. Hub
  2. Belt pulley
  3. Outer ring
  4. Inner ring
  5. Clamp
  6. Spring support
  7. Spring
