Replacing The Generator, V6 Diesel: Refitting

Fit the generator.

Fig 1: Illustration For Step 1-2
Courtesy of SAAB-SCANIA OF AMERICA, INC.

Tightening torque, upper bolt 28 Nm (21 lbf ft)

Tightening torque, lower bolt 58 Nm (43 lbf ft)
Connect the generator cable terminals.
IMPORTANT: Make a note of the belt's direction of rotation. The belt must be refitted for the same direction of rotation as previously.
Refit the multigroove V-belt.
NOTE: Make sure that the belt is correctly positioned on all the pulleys.

Fig 2: Illustration For Step 3
Courtesy of SAAB-SCANIA OF AMERICA, INC.
Fit the subframe, see SUBFRAME, V6 DIESEL ENGINE .
Connect the negative battery cable and fit the battery cover.

Fig 3: Illustration For Step 5
Courtesy of SAAB-SCANIA OF AMERICA, INC.
Set the car's clock.
