Charging Battery

IMPORTANT: An auxiliary starting system must not be used as this could damage the electronics of the car.
To start the car when the battery is discharged, use a booster battery or another car and jumper cables.

The battery can normally be charged with a conventional battery charger.
When boost-charging, the negative terminal of the battery should not be connected.

Fig 1: Charging Battery Below 40A
Courtesy of SAAB-SCANIA OF AMERICA, INC.

The charging current should not exceed 40 A when boost-charging. Max. charging time: 1.5 hours.

IMPORTANT: Never boost-charge a battery if the voltage is below 12 V and the battery is more than 2 years old.
If the battery is completely discharged due to the lights or some other source of consumption having been left on, a weak starting charge should be provided to initiate the chemical process in the battery. If this is the case, start charging with 3 A current (it must not exceed 5 A) for 24 hours or until the charging current has dropped to its lowest stable value.
Gas starts to form in the battery at 14.4 V.

If possible, a battery charger capable of delivering a pulsating charging current should be used.

Fig 2: Charging Battery Below 30A For 24 Hours

Courtesy of SAAB-SCANIA OF AMERICA, INC.
