Grounding point G3: Notes

Fig 1: Identifying Grounding Point G3
G03825852Courtesy of SAAB-SCANIA OF AMERICA, INC.

Location:  In boot below left light cluster

The grounding point is connected with grounding point G29 via the boot electrical centre 701.
