VTD Model

Remove the transmission assembly from the vehicle.

Remove rear vehicle speed sensor, and separate the transmission case and extension case.

Remove the rear drive shaft.

Set the range select lever to "P".

Straighten the staked portion, and remove the lock nut.

Fig 1: Removing Lock Nut

Courtesy of SAAB-SCANIA OF AMERICA, INC.

Using the ST1 and ST2, extract the reduction driven gear.

ST1 32005144 PULLER

ST2 32005174 PULLER SET

Pull out the center differential assembly.
