Center Differential Carrier: Assembly

Install the thrust washer onto the intermediate shaft.

Install thrust bearing onto the intermediate shaft.

Install the pinion gears and washers.

Insert the shaft into the center differential assembly.

Install the snap ring.

Using a press, install a new ball bearing into the center differential assembly.

ST 32005088 REMOVER

Fig 1: Installing Pinion Gears And Washers

Courtesy of SAAB-SCANIA OF AMERICA, INC.

1. Plate
2. Center differential carrier

Apply Vaseline onto the seal ring outer surface and shaft grooves.

Apply ATF to new seal rings and install them.
