Rear Door Glass

Fig 1: Identifying Rear Door Glass Components

Courtesy of SAAB-SCANIA OF AMERICA, INC.

1. Glass
2. Door sash (Front)
3. Door sash (Rear)
4. Weather strip
5. Stabilizer (Outer)
6. Regulator ASSY
7. Stabilizer (Inner)
8. Motor ASSY

Tightening torque: Nm (kgf-m, ft-lb)

T1: 7.4 (0.75, 5.5)

T2: 13.7 (1.4, 10.1)
