Keyless Transmitter Battery

Measure the voltage between battery (+) terminal and (- ) terminal.

NOTE:

Battery discharge occurs during measurement. Complete the measurement within 5 seconds.

Fig 1: Measuring Voltage Between Battery (+) Terminal And (- ) Terminal
Courtesy of SAAB-SCANIA OF AMERICA, INC.

Resistance 47 Ohm

TESTER CONNECTION

Tester connection		Standard
(+)	(- )	Standard
Battery (+) terminal	Battery ( - ) terminal	2.5 - 3.0 V

If NG, replace the battery. (Use CR1620 or equivalent.)
