Reduction Drive Gear: Installation

Install the reduction drive gear assembly.

NOTE: Insert it fully into position until the bearing shoulder bottoms.

Fig 1: Installing Reduction Drive Gear Assembly

Courtesy of SAAB-SCANIA OF AMERICA, INC.

Install the reduction driven gear.

Combine the transmission case with the extension case, and install rear vehicle speed sensor.

Install the transmission assembly to the vehicle.
