Rear wheel speed sensor (298RL, RR)
REAR WHEEL SPEED SENSOR (298RL, RR) TECHNICAL DATA
| Signal form | PWM (pulse ratio) 50% |
| Frequency | 0-2000 Hz |
| Signal current, low (Ilow ) | Nominal 7.0mA min 5.6 mA max 8.4 mA |
| Signal current, high (Ihigh ) | Nominal 14.0 mA min 11.2 mA max 16.8 mA |
| Pulses | 48 pulses/rotation |
| Distance between the perforated disc and sensor (not adjustable) | 0.2-1.3 mm |
