Generator Specifications

Fig 1: Generator Specifications (2.3 & 3.0 L- 130 Amp)
G00324576Courtesy of SAAB-SCANIA OF AMERICA, INC.
Fig 2: Generator Specifications (3.0 L - 140 Amp)
G00371143Courtesy of SAAB-SCANIA OF AMERICA, INC.
