Control module ground: Diagnostics

If there is no ground connection, communication with the TCM will not be possible. No diagnostic trouble code is generated.

TCM in Limp-Home mode.

Fig 1: Control Module Grounding Connection Diagram (G38)

Courtesy of SAAB-SCANIA OF AMERICA, INC.
