Starter Motor For 4-Cyl Petrol Engine: Notes

Fig 1: Cross Sectional View Of Starter Motor For 4-Cyl Petrol

Courtesy of SAAB-SCANIA OF AMERICA, INC.

PETROL ENGINE STARTER MOTOR SPECIFICATIONS

Type designation	Mitsubishi Electric M000T86781
Power	1.4 kW
No. of teeth on starter motor pinion	10
Number of teeth on ring gear	135
Ratio engine/starter motor	13, 5:1
