To fit

  1. Spray the contacts in the relay holder with Kontakt 61 (part no. 30 04 520).
  2. Fit the relay.
    Fig 1: Identifying A/C Relay
    G03503740Courtesy of SAAB-SCANIA OF AMERICA, INC.
  3. Fit the lid.
