Transmission fluid temperature sensor: Diagnostics
WARNING: This page is about a different variant/trim than selected.
A fault in the temperature sensor can generate the following 3 diagnostic trouble codes:
- If the temperature increases or decreases too slowly during the first 15 minutes of driving, diagnostic trouble code P0711 will be generated.
- If there is a short to B -, the diagnostic trouble code P0712 is generated.
- If there is an open circuit/short to B+ or open circuit, diagnostic trouble code P0713 is generated.
