LED (Light Emitting Diode)
Courtesy of SAAB-SCANIA OF AMERICA, INC. LED (Light Emitting Diode) LOCATION AND COLOR
| Location |
In the centre of the dashboard |
| Colour |
Red |
| Power supply |
: Pin No. |
2 |
| Ground: |
Pin No. |
1 |
| Current limit from electronic control module |
20 mA |
