Installing dashboard insert

Fig 1: Tightening fastening screws

Courtesy of PORSCHE OF NORTH AMERICA, INC.

1. Position dashboard insert -1-  on the dashboard and screw into place with the seven fastening screws -2-  . → Tightening torque: 2.0 ftlb.  See Fig 1.
