Installing cup holder

  1. Installing cup holder

    Push cup holder -2-  into the shaft of the retaining bracket -3-  . Make sure that the metal clip -1-  engages.

    Refer to DISASSEMBLING AND ASSEMBLING THE INSTRUMENT PANEL .

Fig 1: Installing Cup Holder
G03155340Courtesy of PORSCHE OF NORTH AMERICA, INC.
