Installation Procedure

WARNING: This page is about a different car, the 2011 Chevrolet Aveo. However, it is still accessible from the selected car via links, so may be relevant.
    Fig 1: U-Clamp Bolts & Stabilizer Bar
    GM1241980Courtesy of GENERAL MOTORS CORP.
    CAUTION: Refer to Fastener Caution .
  1. Install the U-clamps and the stabilizer bar to the crossmember and tighten to 25 N.m (18 lb ft).
  2. Install the crossmember assembly. Refer to Front Suspension Crossmember Replacement .
