Headlamp Switch Replacement
WARNING: This page is about a different car, the 2007 Buick LaCrosse and 2007 Buick Allure. However, it is still accessible from the selected car via links, so may be relevant.
Headlamp Switch Replacement
| Callout | Component Name |
|---|---|
|
NOTE:
Refer to Fastener Notice
. Fastener Tightening Specifications:
Refer to Fastener Tightening Specifications
. |
|
| 1 | Trim Plate, Instrument Panel Cluster Refer to Instrument Panel Cluster Trim Plate Bezel Replacement . |
| 2 | Screw, Instrument Panel Cluster Trim Plate (Qty: 2) Tighten: 2 N.m (18 lb in) |
| 3 | Switch Assembly, Fog Lamp and Headlamp |
