Exhaust Manifold Heat Shield Replacement - Left: Notes

    Fig 1: View Of Left Exhaust Manifold Heat Shield & Bolts
    GM1087638Courtesy of GENERAL MOTORS CORP.
  1. Remove the heat shield bolts (3).
  2. Remove the heat shield (2) from the exhaust manifold.
