Fuel Rail Assembly

Fig 1: Identifying Fuel Injector Insulator Cups

Courtesy of GENERAL MOTORS CORP.

The fuel rail assembly attaches to the engine intake manifold. The fuel rail assembly performs the following functions:

• Positions the injectors in the intake manifold
• Distributes fuel evenly to the injectors
• Integrates the fuel pressure regulator into the fuel metering system
