Seat Belt Guide Replacement - Front

Fig 1: Seat Belt Guide - Front
GM1551165Courtesy of GENERAL MOTORS CORP.
Seat Belt Guide Replacement - Front

Callout Component Name
NOTE: Refer to Fastener Notice in Cautions and Notices.
Fastener Tightening Specifications:  Refer to Fastener Tightening Specifications .Preliminary Procedures: Remove the head restraint. Refer to Head Restraint Replacement - Front Seat .
1 Guide, Seat Shoulder Belt
