Removal Procedure

IMPORTANT: Motor and actuator must be removed as an assembly. Do not attempt separation of motor and actuator. Replacement parts are not available separately.

Remove the door trim panel. Refer to Trim Panel Replacement - Side Front Door or Trim Panel Replacement - Side Rear Door .
Remove the electrical connection from the power window motor.
Remove the power window motor retaining bolts.

Fig 1: View Of Power Window Motor Assembly

Courtesy of GENERAL MOTORS CORP.

Remove the power window motor assembly from the vehicle.
