Indicator/Warning Message Description and Operation: Notes

WARNING: This page is about a different car, the 2004 Chevrolet Monte Carlo and 2004 Chevrolet Impala. However, it is still accessible from the selected car via links, so may be relevant.

Instrument Panel Cluster (IPC) Indicators

Symbol	Description
Courtesy of GENERAL MOTORS CORP.	ABS: Refer to ABS Description and Operation in Antilock Brake System
Courtesy of GENERAL MOTORS CORP.	Air Bag: Refer to SIR System Description and Operation in SIR
Courtesy of GENERAL MOTORS CORP. Export BRAKE (Domestic)	Brake: Refer to Brake Warning System Description and Operation in Hydraulic Brakes
CRUISE	Cruise: Refer to Cruise Control Description and Operation in Cruise Control
Courtesy of GENERAL MOTORS CORP.	Fasten Safety Belt: Refer to Seat Belt System Description and Operation in Seat Belts
Courtesy of GENERAL MOTORS CORP.	High Beam: Refer to Exterior Lighting Systems Description and Operation in Lighting Systems
Courtesy of GENERAL MOTORS CORP.	Malfunction Indicator Lamp (MIL): Refer to Powertrain Control Module (PCM) Description in Engine Controls - 3.4L or Powertrain Control Module (PCM) Description in Engine Controls - 3.8L
TRAC OFF	Traction Control Off: Refer to ABS Description and Operation in Antilock Brake System
Courtesy of GENERAL MOTORS CORP.	Turn Signals: Refer to Exterior Lighting Systems Description and Operation in Lighting Systems

Message Center Indicators

Symbol	Description
Courtesy of GENERAL MOTORS CORP. (Export) CHANGE ENGINE OIL (Domestic)	Change Engine Oil: Refer to Indicator/Warning Message Description and Operation
Courtesy of GENERAL MOTORS CORP.	Charge: Refer to Charging System Description and Operation in Engine Electrical
Courtesy of GENERAL MOTORS CORP. (Export) DOOR AJAR (Domestic)	Door Ajar: Refer to Door Ajar Indicator Description and Operation in Doors
Courtesy of GENERAL MOTORS CORP. (Export) HIGHBEAM OUT (Domestic)	Highbeam Out: Refer to Exterior Lighting Systems Description and Operation in Lighting Systems
Courtesy of GENERAL MOTORS CORP. (Export) HOT COOLANT TEMP (Domestic)	Hot Coolant Temperature: Refer to Cooling System Description and Operation in Engine Cooling
Courtesy of GENERAL MOTORS CORP. (Export) INTRUSION OFF (Domestic)	Intrusion Off: Refer to Indicator/Warning Message Description and Operation
Courtesy of GENERAL MOTORS CORP. (Export) INTRUSION ON (Domestic)	Intrusion On: Refer to Indicator/Warning Message Description and Operation
Courtesy of GENERAL MOTORS CORP. (Export) LOW BRAKE FLUID (Domestic)	Low Brake Fluid: Refer to Brake Warning System Description and Operation in Hydraulic Brakes
Courtesy of GENERAL MOTORS CORP. (Export) LOW COOLANT LEVEL (Domestic)	Low Coolant Level: Refer to Cooling System Description and Operation in Engine Cooling
Courtesy of GENERAL MOTORS CORP. (Export) LOW ENG OIL LEVEL (Domestic)	Low Engine Oil Level: Refer to Indicator/Warning Message Description and Operation
Courtesy of GENERAL MOTORS CORP. (Export) LOW FUEL (Domestic)	Low Fuel: Refer to Indicator/Warning Message Description and Operation
Courtesy of GENERAL MOTORS CORP. (Export) LOW OIL PRESSURE (Domestic)	Low Oil Pressure: Refer to Indicator/Warning Message Description and Operation
Courtesy of GENERAL MOTORS CORP. (Export) LOW TIRE PRESSURE (Domestic)	Low Tire Pressure: Refer to Tire Pressure Monitor Description and Operation in Tire Pressure Monitoring
Courtesy of GENERAL MOTORS CORP. (Export) LOW WASHER FLUID (Domestic)	Low Washer Fluid: Refer to Wiper/Washer System Description and Operation in Wipers/Washer Systems
Courtesy of GENERAL MOTORS CORP. (Export) REDUCED ENGINE POWER (Domestic)	Reduced Engine Power: Refer to Indicator/Warning Message Description and Operation
Courtesy of GENERAL MOTORS CORP. (Export) SERVICE TRACTION SYSTEM (Domestic)	Service Traction System: Refer to ABS Description and Operation in Antilock Brake System
Courtesy of GENERAL MOTORS CORP. (Export) SECURITY (Domestic)	Security: Refer to Theft Systems Description and Operation in Theft Deterrent
Courtesy of GENERAL MOTORS CORP. (Export) SERVICE VEHICLE SOON (Domestic)	Service Vehicle Soon: Refer to Indicator/Warning Message Description and Operation
Courtesy of GENERAL MOTORS CORP. (Export) TRACTION ACTIVE (Domestic)	Traction Active: Refer to ABS Description and Operation in Antilock Brake System
Courtesy of GENERAL MOTORS CORP. (Export) TRUNK OPEN (Domestic)	Trunk Ajar: Refer to Trunk Ajar Indicator Always On in Body Rear End
Courtesy of GENERAL MOTORS CORP. (Export) OVER SPEED (Domestic)	Vehicle Overspeed: Refer to Indicator/Warning Message Description and Operation
