Installation Procedure
- Reach your hand through the access opening and install the microphone to the overhead console at the left rear corner of the overhead console.
- Snap the microphone bracket to the overhead console.
- Connect the microphone connector (2) to the mating 2-way connector.
- Install the overhead console door (1).
Install the screws securing the overhead console door.
Tighten
Tighten the screws to 10 N.m (89 lb in).
