Installation Procedure

  1. Install the bulb to the IP compartment lamp switch (2)
  2. Align the switch to the opening in the IP carrier.
  3. Install the switch (2) through the opening in the IP carrier. Press the switch until fully seated.
  4. Close the IP compartment door.
    Fig 1: Installing IP Compartment Lamp
    G01767584Courtesy of GENERAL MOTORS CORP.
